ROHM recommends a thermal pad design with a minimum size of 2.5mm x 2.5mm, and a thermal via array with a minimum of 10 vias, 0.3mm in diameter, and 1.5mm pitch to minimize thermal resistance.
To ensure reliability, follow the recommended derating guidelines, use a heat sink if necessary, and ensure the device is operated within the specified temperature range. Additionally, consider using a thermally conductive material, such as a thermal interface material (TIM), between the device and heat sink.
The maximum allowed voltage for the PTZTFTE256.2B is 2.8V, as specified in the datasheet. Exceeding this voltage may damage the device or affect its reliability.
While the PTZTFTE256.2B is primarily designed for low-frequency applications, it can be used in high-frequency applications up to 100kHz. However, the device's performance and reliability may be affected at higher frequencies. Consult ROHM's application notes or contact their support team for guidance on high-frequency usage.
To prevent ESD damage, handle the PTZTFTE256.2B with an anti-static wrist strap or mat, and ensure the assembly process is ESD-controlled. Additionally, consider using ESD-protective packaging and follow ROHM's recommended handling procedures.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
PTZTFTE256.2B Overview
Use the download button to access the PTZTFTE256.2B schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PTZTF,
or try a keyword search, such as Zener Diodes
