The recommended land pattern for PU2512FKM130R003L is a rectangular pad with a size of 2.5mm x 1.2mm, with a non-solder mask defined (NSMD) pad and a solder mask opening of 2.3mm x 1.0mm.
Yes, PU2512FKM130R003L is rated for operation up to 150°C, making it suitable for high-temperature applications. However, it's essential to ensure that the component is properly derated to prevent overheating and premature failure.
Yes, PU2512FKM130R003L is compatible with lead-free soldering processes, including RoHS and WEEE compliant soldering. The component is designed to withstand the higher temperatures associated with lead-free soldering.
The MSL of PU2512FKM130R003L is MSL 2, which means it can withstand exposure to moisture for up to 4 days without requiring baking or other special handling procedures.
While PU2512FKM130R003L is designed to operate in a variety of environments, it's not recommended for use in applications with extremely high humidity or moisture. The component may be susceptible to moisture-related failures in such environments.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
PU2512FKM130R003L Overview
Use the download button to access the PU2512FKM130R003L schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PU251,
or try a keyword search, such as Metal Strip Resistor
