Q48SK12050PRDH - Delta Electronics

Q48SK12050PRDH Details

• Manufacturer Part Number:

  Q48SK12050PRDH

• Part Life Cycle Code:

  Active

• Package Description:

  1/4 BRICK PACKAGE-15

• ECCN Code:

  EAR99

• Manufacturer:

  Delta Electronics Inc

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CSA, EN, IEC, UL

• Efficiency (Main Output):

  96.3%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDMA-X15

• Length:

  58.4 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  15

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  50 A

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  9.6 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,15LEAD,2.1

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, OVER TEMPERATURE, UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.02 Vrms

• Screening Level:

  CSA/EN/IEC/UL 62368-1

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  DUAL

• Total Power Output-Max:

  600 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.196 s

• Width:

  36.8 mm
