QCN-12+ - Mini-Circuits

QCN-12+ Details

• Manufacturer Part Number:

  QCN-12+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  0.120 X 0.060 INCH, 0.035 INCH HEIGHT, ROHS COMPLIANT, ULTRA SMALL, CERAMIC, CASE FV1206-1, 6 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  6.92

• Additional Feature:

  ISOLATION-MIN (DB):14

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  41.76 dBm

• Insertion Loss-Max:

  1 dB

• Isolation-Min:

  14 dB

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Max:

  1375 MHz

• Operating Frequency-Min:

  800 MHz

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Equivalence Code:

  SOLCC6,.06,40

• RF/Microwave Device Type:

  COMBINER

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn) - with Nickel (Ni) barrier

• VSWR-Max:

  1.5
