QHL150300S28 - XP POWER

QHL150300S28 Details

• Manufacturer Part Number:

  QHL150300S28

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  1/4 BRICK PACKAGE-8

• ECCN Code:

  EAR99

• Date Of Intro:

  2019-10-07

• Manufacturer:

  XP Power

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, UL

• Efficiency (Main Output):

  89%

• Input Voltage-Max:

  425 V

• Input Voltage-Min:

  180 V

• Input Voltage-Nom:

  300 V

• JESD-30 Code:

  R-PDFM-P8

• JESD-609 Code:

  e3

• Length:

  57.9 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  5.4 A

• Output Voltage-Max:

  25.2 V

• Output Voltage-Min:

  22.4 V

• Output Voltage-Nom:

  28 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  SHORT CIRCUIT; OUTPUT OVER VOLTAGE; OVER LOAD

• Ripple Voltage (Main Out):

  0.035353 Vrms

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  YES

• Switching Frequency-Max:

  390 kHz

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  MATTE TIN OVER NICKEL

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  150 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.3 s

• Width:

  36.8 mm
