Qorvo provides a recommended PCB layout and thermal management guide in their application note AN-2171, which includes guidelines for thermal vias, heat sinks, and PCB stack-up to ensure optimal performance and thermal dissipation.
Qorvo provides a set of simulation models and design tools, such as the Qorvo GaN Simulator and the QPA5368SR Evaluation Board, to help optimize the biasing and matching networks for specific applications. Additionally, Qorvo's application engineers can provide custom design support and guidance.
While the datasheet specifies an operating temperature range of -40°C to +85°C, Qorvo recommends derating the device's power output and operating temperature to ensure reliable operation over the full temperature range. Consult with Qorvo's application engineers for specific guidance on temperature derating.
Qorvo provides guidelines for EMC and EMI compliance in their application note AN-2172, which includes recommendations for PCB layout, shielding, and filtering to minimize electromagnetic emissions and susceptibility.
Qorvo recommends following the standard ESD handling and storage procedures for GaN devices, including storing the devices in anti-static packaging, handling them with ESD-protected tools and equipment, and avoiding exposure to moisture and extreme temperatures.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
QPA5368SR Overview
Use the download button to access the QPA5368SR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like QPA53,
or try a keyword search, such as RF/Microwave Amplifiers
About Qorvo
Qorvo is a prominent American semiconductor company that specializes in the design and manufacturing of radio frequency (RF) solutions. The company was formed in 2015 through the merger of TriQuint Semiconductor and RF Micro Devices. Qorvo's product portfolio encompasses a wide range of RF components and semiconductor technologies used in various applications, including wireless communications, aerospace and defense, and IoT (Internet of Things) devices.
