Qorvo provides a recommended PCB layout and thermal management guide in their application note AN-2171, which includes guidelines for thermal pad connection, heat sink attachment, and PCB layout considerations.
Qorvo offers a simulation model and design tools, such as the Qorvo GaN Simulator, to help optimize the performance of QPC6614TR13 in specific applications. Additionally, Qorvo's application engineers can provide customized support and guidance.
QPC6614TR13 has undergone rigorous reliability and qualification tests, including JEDEC and AEC-Q101 standards, to ensure its performance and reliability in harsh environments. Details of these tests can be found in the Qorvo reliability report.
While QPC6614TR13 is primarily designed for RF applications, its high-power and high-frequency capabilities make it suitable for non-RF applications such as power supplies or motor control. However, Qorvo recommends consulting with their application engineers to ensure the device meets the specific requirements of the non-RF application.
Qorvo recommends following the standard ESD and moisture-sensitive device handling procedures, as outlined in the Qorvo packaging and handling guide, to prevent damage to the device during storage and handling.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
QPC6614TR13 Overview
Use the download button to access the QPC6614TR13 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like QPC66,
or try a keyword search, such as RF/Microwave Attenuators
About Qorvo
Qorvo is a prominent American semiconductor company that specializes in the design and manufacturing of radio frequency (RF) solutions. The company was formed in 2015 through the merger of TriQuint Semiconductor and RF Micro Devices. Qorvo's product portfolio encompasses a wide range of RF components and semiconductor technologies used in various applications, including wireless communications, aerospace and defense, and IoT (Internet of Things) devices.
