QPL6202QSQ - Qorvo

QPL6202QSQ Details

• Manufacturer Part Number:

  QPL6202QSQ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN-8

• ECCN Code:

  5A991.G

• Manufacturer:

  Qorvo

• YTEOL:

  6

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Gain:

  21.2 dB

• Input Power-Max (CW):

  27 dBm

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Frequency-Max:

  2345 MHz

• Operating Frequency-Min:

  2320 MHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOLCC8,.08,20

• Power Supplies:

  4.5 V

• RF/Microwave Device Type:

  NARROW BAND LOW POWER

• Screening Level:

  AEC-Q100

• Supply Current-Max:

  68 mA

• Surface Mount:

  YES

• Technology:

  E-PHEMT

• VSWR-Max:

  1.33
