R10-E2Y2-S3.2K - TE Connectivity

R10-E2Y2-S3.2K Details

• Manufacturer Part Number:

  R10-E2Y2-S3.2K

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Factory Lead Time:

  37 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  18.7 mm

• Body Height:

  30.2 mm

• Body Length or Diameter:

  24.1 mm

• Coil Current(DC)-Max:

  0.004 A

• Coil Power:

  180 mW

• Coil Resistance:

  3200 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  3 A

• Contact Current(DC)-Max:

  3 A

• Contact Voltage(AC)-Max:

  120 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  1000 Vrms

• Dielectric Strength Between Open Contacts:

  500 Vrms

• End Contact Material:

  SILVER

• Insulation Resistance:

  10000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  29.6mm x 18.7mm x 30.2mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  40 g
