R10805RN02Q - LITTELFUSE

R10805RN02Q Details

• Manufacturer Part Number:

  R10805RN02Q

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• Actuator Length:

  0.5 inch

• Actuator Material:

  NYLON

• Actuator Type:

  FLAT TYPE

• Body Height:

  6.99 mm

• Body Length or Diameter:

  23.37 mm

• Center Contact Material:

  COPPER

• Center Contact Plating:

  SILVER

• Contact (AC) Max Rating R Load:

  5A@125VAC

• Contact Current(AC)-Max:

  5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  .5A@125VDC

• Contact Resistance:

  0.01 mΩ

• Contact Timing:

  MAKE-BEFORE-BREAK

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  125 V

• Dielectric Withstand Volts:

  1000VRMS V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  COPPER

• End Contact Plating:

  SILVER

• Housing Material:

  NYLON

• Indexing Angle:

  36 deg

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  8

• Number of Switch Sections:

  1

• Operating Temperature-Max:

  95 °C

• Operating Temperature-Min:

  -30 °C

• Sealing:

  EPOXY

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP8T

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  Silver (Ag)

• Terminal Length:

  0.28 inch

• Terminal Material:

  COPPER

• Termination Type:

  SOLDER
