R1171J331D-T1-F - Ricoh

R1171J331D-T1-F Details

• Manufacturer Part Number:

  R1171J331D-T1-F

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  TO-252

• Package Description:

  TO-252, 5 PIN

• Pin Count:

  4

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Ricoh Electronic Devices Co Ltd

• Dropout Voltage1-Max:

  0.18 V

• Input Voltage-Max:

  6 V

• Input Voltage-Min:

  2.1 V

• JESD-30 Code:

  R-PSSO-G5

• JESD-609 Code:

  e6

• Length:

  6.54 mm

• Number of Functions:

  1

• Number of Terminals:

  5

• Operating Temperature TJ-Max:

  125 °C

• Output Voltage1-Max:

  3.366 V

• Output Voltage1-Min:

  3.234 V

• Output Voltage1-Nom:

  3.3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TO-252

• Package Equivalence Code:

  SMSIP5H,.37,50TB

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  2.97 mm

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  TIN BISMUTH

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  SINGLE

• Voltage Tolerance-Max:

  2%

• Width:

  6.04 mm
