R1190S075B-E2-FE - Nisshinbo

R1190S075B-E2-FE Details

• Manufacturer Part Number:

  R1190S075B-E2-FE

• Part Life Cycle Code:

  Active

• Package Description:

  HSOP-6

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Nisshinbo Micro Devices

• YTEOL:

  5

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  1.85 V

• Dropout Voltage1-Nom:

  1.1 V

• Input Voltage Absolute-Max:

  18 V

• Input Voltage-Max:

  16 V

• Input Voltage-Min:

  8 V

• JESD-30 Code:

  R-PDSO-G6

• Length:

  5.02 mm

• Line Regulation-Max:

  0.06%

• Load Regulation-Max(%):

  0.25%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current1-Max:

  1 A

• Output Voltage1-Max:

  7.7025 V

• Output Voltage1-Min:

  7.2975 V

• Output Voltage1-Nom:

  7.5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSOP

• Package Equivalence Code:

  SOP6(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG

• Packing Method:

  TR

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  1.85 mm

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.9 mm

• Terminal Position:

  DUAL

• Voltage Tolerance-Max:

  2.7%

• Width:

  3.9 mm
