RECOM recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure good heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
To ensure reliability in high-temperature environments, RECOM recommends derating the module's output power according to the temperature derating curve provided in the datasheet. Additionally, ensuring good airflow and heat dissipation around the module can help to reduce the operating temperature.
RECOM recommends using a low-ESR ceramic capacitor with a value of 10-22uF, 50V or higher, as close to the module's input pins as possible. This helps to filter out input noise and ensure stable operation.
Yes, the R15-100B can be used in a redundant or parallel configuration, but RECOM recommends consulting with their application engineers to ensure proper design and implementation. Additionally, the modules should be synchronized to prevent oscillations and ensure stable operation.
According to RECOM, the typical MTBF for the R15-100B is >1.5 million hours at 40°C, calculated according to MIL-HDBK-217F. However, this value may vary depending on the specific application and operating conditions.
