R25-11D10-12 - NTE ELECTRONICS

R25-11D10-12 Details

• Manufacturer Part Number:

  R25-11D10-12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  NTE Electronics Inc

• YTEOL:

  0

• Body Breadth:

  12.7 mm

• Body Height:

  15.6 mm

• Body Length or Diameter:

  29 mm

• Coil Current(DC)-Max:

  0.042 A

• Coil Operate Voltage(DC):

  9.6 V

• Coil Power:

  500 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  270 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  10A@120VAC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  10 A

• Contact (DC) Max Rating R Load:

  10A@28VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  120 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• End Contact Material:

  Silver Alloy

• Input Switching Control Type:

  Random

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operate Time:

  8 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  29mm x 12.7mm x 15.6mm

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  5 ms

• Surface Mount:

  NO

• Terminal Length:

  0.0033020066040132085 inch

• Termination Type:

  SOLDER
