R2A20162SP#W5 - Renesas Electronics

R2A20162SP#W5 Details

• Manufacturer Part Number:

  R2A20162SP#W5

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOP

• Package Description:

  SOP-8

• Pin Count:

  8

• Manufacturer Package Code:

  PRSP0008DE

• ECCN Code:

  3A991

• HTS Code:

  8542.39.00.40

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Analog Output Voltage-Max:

  5.4 V

• Analog Output Voltage-Min:

  0.1 V

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  R-PDSO-G8

• Length:

  4.85 mm

• Linearity Error-Max (EL):

  0.39062%

• Number of Bits:

  8

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP8,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Seated Height-Max:

  2.03 mm

• Settling Time-Max:

  150 µs

• Supply Current-Max:

  2.5 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  4.4 mm
