R30N-3011-85-1012 - Relpol

R30N-3011-85-1012 Details

• Manufacturer Part Number:

  R30N-3011-85-1012

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.75

• Manufacturer:

  Relpol SA

• YTEOL:

  7

• Body Breadth:

  27.6 mm

• Body Height:

  20.5 mm

• Body Length or Diameter:

  32.5 mm

• Coil Current(DC)-Max:

  0.075 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  900 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  160 Ω

• Coil Voltage(DC)-Max:

  15.6 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  30A@300VAC

• Contact Current(AC)-Max:

  30 A

• Contact Current(DC)-Max:

  30 A

• Contact (DC) Max Rating R Load:

  30A@110VDC

• Contact Resistance:

  30 mΩ

• Contact Voltage(AC)-Max:

  300 V

• Contact Voltage(DC)-Max:

  110 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  Silver Tin Oxide

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  5

• Operate Time:

  15 ms

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  32.5mm x 27.6mm x 20.5mm

• Reference Standard:

  CUL; EAC; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  CHANGE-OVER

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Sealing:

  IP67; RT3

• Surface Mount:

  NO

• Terminal Length:

  0.004201168402336804 inch

• Termination Type:

  SOLDER
