R591722610 - Radiall

R591722610 Details

• Manufacturer Part Number:

  R591722610

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  2 Weeks, 6 Days

• Manufacturer:

  Radiall

• YTEOL:

  8

• Additional Feature:

  WITH POSITIVE + COMMON

• Body Height:

  37.3 mm

• Body Length or Diameter:

  30.5 mm

• Characteristic Impedance:

  50 Ω

• Coil Current(DC)-Max:

  0.2 A

• Coil Operate Voltage(DC):

  10.2 V

• Coil Power:

  40000 mW

• Coil Resistance:

  60 Ω

• Coil Voltage(DC)-Max:

  13 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Electrical Life:

  10000000 Cycle(s)

• Input Switching Control Type:

  Random

• Insertion Loss-Max:

  0.6 dB

• Isolation-Max:

  55 dB

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  16

• Operating Frequency-Max:

  26500 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  30.5mm X 37.3mm

• Relay Action:

  LATCHED

• Relay Function:

  SP6T

• Relay Type:

  RF COAXIAL RELAY

• Surface Mount:

  NO

• Switching Time:

  10 ms

• Termination Type:

  CONNECTOR AND SOLDER

• VSWR:

  1.6
