R7S721020VCBG#AC1 - Renesas Electronics

R7S721020VCBG#AC1 Details

• Manufacturer Part Number:

  R7S721020VCBG#AC1

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  LFBGA

• Package Description:

  BGA-176

• Pin Count:

  176

• Manufacturer Package Code:

  PLBG0176KA

• Country Of Origin:

  Japan

• ECCN Code:

  3A991.A.2

• HTS Code:

  8542.31.00.50

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  10

• Address Bus Width:

  26

• Bit Size:

  32

• Boundary Scan:

  YES

• Clock Frequency-Max:

  13.33 MHz

• External Data Bus Width:

  32

• Format:

  FLOATING POINT

• Integrated Cache:

  YES

• JESD-30 Code:

  S-PBGA-B176

• Length:

  8 mm

• Low Power Mode:

  YES

• Moisture Sensitivity Level:

  3

• Number of DMA Channels:

  16

• Number of External Interrupts:

  108

• Number of Serial I/Os:

  7

• Number of Terminals:

  176

• On Chip Data RAM Width:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFBGA

• Package Equivalence Code:

  BGA176,15X15,20

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, LOW PROFILE, FINE PITCH

• Qualification Status:

  Not Qualified

• RAM (words):

  3145728

• Seated Height-Max:

  1.4 mm

• Speed:

  400 MHz

• Supply Current-Max:

  492 mA

• Supply Voltage-Max:

  1.26 V

• Supply Voltage-Min:

  1.1 V

• Supply Voltage-Nom:

  1.18 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  8 mm

• uPs/uCs/Peripheral ICs Type:

  MICROPROCESSOR, RISC
