RA6998-BLB - COILCRAFT

RA6998-BLB Details

• Manufacturer Part Number:

  RA6998-BLB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  0

• Additional Feature:

  LENGTH AND HEIGHT DIMENSION INCLUDE TERMINAL ALSO

• Height:

  9.14 mm

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  18 V

• JESD-609 Code:

  e3

• Length:

  23.37 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  12 V

• Packing Method:

  TR

• Primary Inductance:

  80 µH

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  20.57 mm
