RAA230231GSB#HA0 - Renesas Electronics

RAA230231GSB#HA0 Details

• Manufacturer Part Number:

  RAA230231GSB#HA0

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  HTSSOP

• Package Description:

  HTSSOP-20

• Pin Count:

  20

• Manufacturer Package Code:

  PTSP0020JF

• ECCN Code:

  5A002

• Factory Lead Time:

  52 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Additional Feature:

  0.8V TO 6V ADDITIONAL ADJUSTABLE OUTPUT IS AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  16 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-PDSO-G20

• Length:

  6.5 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  20

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  3 A

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSOP20,.25,25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Protections:

  SHORT CIRCUIT, THERMAL, UNDER VOLTAGE

• Seated Height-Max:

  1.1 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  9.9 W

• Trim/Adjustable Output:

  YES

• Width:

  4.4 mm
