RAC04-15SK/277 - RECOM Power

RAC04-15SK/277 Details

• Manufacturer Part Number:

  RAC04-15SK/277

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DMA,

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Date Of Intro:

  2019-06-14

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  6

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL, CAN, CSA , IEC, EN

• Efficiency (Main Output):

  80%

• Input Voltage-Max:

  305 V

• Input Voltage-Min:

  80 V

• Input Voltage-Nom:

  277 V

• JESD-30 Code:

  R-PDMA-P6

• JESD-609 Code:

  e3

• Length:

  36.7 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.267 A

• Output Voltage-Max:

  15.15 V

• Output Voltage-Min:

  14.85 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OUTPUT OVER VOLTAGE; OUTPUT OVER CURRENT; SHORT CIRCUIT

• Screening Level:

  IEC/EN/UL 62368-1

• Seated Height-Max:

  17.9 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  4 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.02 s

• Width:

  27.2 mm
