RAC04NE-05SK/277 - RECOM Power

RAC04NE-05SK/277 Details

• Manufacturer Part Number:

  RAC04NE-05SK/277

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-5

• Reach Compliance Code:

  Unknown

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  6

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CAN, CE, CSA, EN, IEC, UL

• Efficiency (Main Output):

  75%

• Input Voltage-Max:

  305 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-PDMA-P5

• Length:

  37 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.8 A

• Output Voltage-Max:

  5.1 V

• Output Voltage-Min:

  4.9 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER VOLTAGE; OVER CURRENT; SHORT CIRCUIT

• Screening Level:

  IEC/UL 62368-1

• Seated Height-Max:

  18.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  4 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.015 s

• Width:

  24 mm
