RAC05E-04SKT - RECOM Power

RAC05E-04SKT Details

• Manufacturer Part Number:

  RAC05E-04SKT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DMA,

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  6

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CB, CE, EAC, IEC

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  72%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  90 V

• Input Voltage-Nom:

  230 V

• JESD-30 Code:

  R-PDMA-P4

• Length:

  32.1 mm

• Line Regulation-Max:

  2%

• Load Regulation-Max:

  2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -25 °C

• Output Current-Max:

  1.25 A

• Output Voltage-Max:

  4.12 V

• Output Voltage-Min:

  3.88 V

• Output Voltage-Nom:

  4 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; OVER VOLTAGE

• Ripple Voltage (Main Out):

  0.0247 Vrms

• Seated Height-Max:

  22 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  130 kHz

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  5 W

• Trim/Adjustable Output:

  NO

• Width:

  27.1 mm
