RACM40-24SK-T - RECOM Power

RACM40-24SK-T Details

• Manufacturer Part Number:

  RACM40-24SK-T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  7

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  EN,IEC

• Efficiency (Main Output):

  90%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  80 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-XDMA-P6

• Length:

  83.23 mm

• Line Regulation-Max:

  0.05%

• Load Regulation-Max:

  0.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1.667 A

• Output Voltage-Max:

  24.48 V

• Output Voltage-Min:

  23.52 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; OVER VOLTAGE ; SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.08484 Vrms

• Screening Level:

  IEC60601-1; EN/IEC 62368-1

• Seated Height-Max:

  30.4 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  40 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.23 s

• Width:

  46.43 mm
