RC2512JK-7W100RL - Yageo Group

RC2512JK-7W100RL Details

• Manufacturer Part Number:

  RC2512JK-7W100RL

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8533.21.00.30

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  YAGEO Corporation

• YTEOL:

  10

• Additional Feature:

  LASER TRIMMABLE

• Construction:

  Rectangular

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  0.55 mm

• Package Length:

  6.35 mm

• Package Style:

  SMT

• Package Width:

  3.1 mm

• Packing Method:

  TR, EMBOSSED PLASTIC, 7 INCH

• Rated Power Dissipation (P):

  2 W

• Rated Temperature:

  70 °C

• Resistance:

  100 Ω

• Resistor Type:

  FIXED RESISTOR

• Size Code:

  2512

• Surface Mount:

  YES

• Technology:

  METAL GLAZE/THICK FILM

• Temperature Coefficient:

  200 ppm/°C

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Terminal Shape:

  WRAPAROUND

• Tolerance:

  5%

• Working Voltage:

  200 V
