RCDE-48-0.70 - RECOM Power

RCDE-48-0.70 Details

• Manufacturer Part Number:

  RCDE-48-0.70

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-24/9

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Date Of Intro:

  2020-01-30

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  7.7

• Analog IC - Other Type:

  DC-DC CURRENT SOURCE MODULE

• Approvals:

  EN, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  97%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  6 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-PDMA-P9

• Length:

  32.1 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.7 A

• Output Voltage-Max:

  52 V

• Output Voltage-Min:

  3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  THERMAL

• Ripple Voltage (Main Out):

  0.10605 Vrms

• Seated Height-Max:

  12.8 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  36.4 W

• Trim/Adjustable Output:

  NO

• Width:

  20.6 mm
