RCJ-011 - Same Sky

RCJ-011 Details

• Manufacturer Part Number:

  RCJ-011

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Same Sky

• YTEOL:

  7.98

• Audio Type:

  PHONO

• Board Mounting Option:

  MOUNTING FLANGE

• Body Breadth:

  0.472 inch

• Body Depth:

  0.571 inch

• Body Diameter:

  0.327 inch

• Body Length:

  0.417 inch

• Body/Shell Style:

  JACK

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  RCA

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Finish Termination:

  Tin (Sn)

• Contact Gender:

  FEMALE

• Contact Material:

  BRASS

• Contact Resistance:

  30 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  700VAC V

• Durability:

  5000 Cycles

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYAMIDE9T

• JESD-609 Code:

  e3

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  2

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Polarization Key:

  POLARIZED HOUSING

• Shell Finish:

  TIN

• Shell Material:

  STEEL

• Terminal Length:

  0.156 inch

• Termination Type:

  SOLDER
