RDC2072S12 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  XP Power recommends a PCB layout with a large copper area connected to the module's thermal pad to dissipate heat efficiently. A minimum of 2 oz copper thickness is recommended, and the copper area should be at least 1 inch x 1 inch in size.
• Can I use the RDC2072S12 in a high-vibration environment?
  Yes, the RDC2072S12 is designed to withstand vibrations up to 10G peak acceleration, making it suitable for use in high-vibration environments. However, it's essential to ensure proper mounting and screw torque to prevent damage.
• How do I ensure the module's reliability in high-temperature applications?
  To ensure reliability in high-temperature applications, XP Power recommends derating the output power by 2.5% per degree Celsius above 50°C. Additionally, ensure good airflow around the module, and consider using a heat sink or thermal interface material to reduce thermal resistance.
• What is the recommended input fuse rating for the RDC2072S12?
  XP Power recommends using a fuse with a rating of 5A to 10A, depending on the input voltage and system requirements. The fuse should be able to handle the inrush current during startup and provide protection against overcurrent faults.
• Can I use the RDC2072S12 in a redundant configuration?
  Yes, the RDC2072S12 can be used in a redundant configuration to achieve high availability and reliability. XP Power recommends using a diode ORing circuit or a redundant controller to ensure seamless switchover between modules in case of a failure.
