The maximum capacitive load is not explicitly stated in the datasheet, but as a general rule, RECOM recommends limiting the output capacitance to 10-20 times the output capacitance of the converter itself, which is 100nF in this case. So, the maximum capacitive load would be around 2-4uF.
While the datasheet specifies an operating temperature range of -40°C to +85°C, the converter can be derated for use in higher temperature environments. However, it's recommended to consult with RECOM's application engineers to determine the maximum operating temperature and any necessary derating.
The REC5A-2405SW/H2/X1 meets various safety certifications, including UL60950-1, EN60950-1, and IEC60950-1. However, to ensure compliance with specific application requirements, it's recommended to review the certification documents and consult with RECOM's application engineers if necessary.
RECOM recommends following the layout guidelines provided in the datasheet, which include keeping the input and output capacitors as close as possible to the converter, using a star-point connection for the input capacitors, and ensuring a minimum spacing of 1.5mm between the capacitors and other components.
Yes, the REC5A-2405SW/H2/X1 can be used in a redundant or parallel configuration, but it's essential to follow RECOM's guidelines for paralleling and redundancy, which include using identical converters, ensuring proper synchronization, and implementing adequate overcurrent protection.
