REC8E-1215D/CTRL/X1 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  RECOM recommends a PCB layout with a large copper area connected to the module's thermal pad, and a minimum of 2oz copper thickness to ensure good heat dissipation. A thermal via array under the module can also improve thermal performance.
• How do I ensure the module's reliability in high-vibration environments?
  To ensure reliability in high-vibration environments, RECOM recommends following the recommended PCB layout and mounting guidelines, using a secure screw or adhesive to fix the module to the PCB, and applying a conformal coating to protect against moisture and contaminants.
• What is the maximum allowed capacitance for the output filter capacitor?
  The maximum allowed capacitance for the output filter capacitor is 47uF. Exceeding this value may affect the module's stability and performance.
• Can I use this module in a redundant configuration for high-reliability applications?
  Yes, the REC8E-1215D/CTRL/X1 can be used in a redundant configuration for high-reliability applications. However, it's essential to ensure that the modules are properly synchronized and that the system is designed to handle the increased power consumption and heat generation.
• What is the recommended input fuse rating for this module?
  RECOM recommends using a fuse with a rating of 2A to 5A, depending on the specific application and input voltage. The fuse should be able to handle the module's peak inrush current and provide adequate protection against overcurrent conditions.
