RF180-12 - Teledyne Technologies

RF180-12 Details

• Manufacturer Part Number:

  RF180-12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Teledyne Technologies Inc

• YTEOL:

  8.45

• Body Breadth:

  8.51 mm

• Body Height:

  7.62 mm

• Body Length or Diameter:

  11.05 mm

• Coil Current(DC)-Max:

  0.03 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  480 mW

• Coil Release Voltage(DC):

  9 V

• Coil Resistance:

  500 Ω

• Coil Voltage(DC)-Max:

  16 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  .5A@28VDC

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  2 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  11.05mm x 8.51mm x 7.62mm

• Relay Action:

  LATCHED

• Relay Function:

  DPDT

• Relay Type:

  RF RELAY

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Switching Time:

  2 ms

• Termination Type:

  SOLDER
