RFAM3620SR - Qorvo

Description: 45 - 1218 MHz, 36dB, 12V, GaAs pHEMT-MESFET, Edge QAM MCM

Download RFAM3620SR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
RFAM3620SR - Qorvo - PCB symbol
click to zoom
PCB Footprints
RFAM3620SR - Qorvo PCB footprint - Other - Other - 21 pin, 11.0 mm x 11.0 mm x 1.375 mm package
click to zoom
3D Models
RFAM3620SR - Qorvo - 3D model - Other - 21 pin, 11.0 mm x 11.0 mm x 1.375 mm package
click to zoom

RFAM3620SR Details

  • Manufacturer Part Number:

    RFAM3620SR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    5A991.G

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    Qorvo

  • JESD-609 Code:

    e4

  • RF/Microwave Device Type:

    WIDE BAND LOW POWER

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

RFAM3620SR Frequently Asked Questions (FAQs)

  • Qorvo provides a separate application note (AN-12033) that outlines the recommended PCB layout and design guidelines for the RFAM3620SR. It's essential to follow these guidelines to ensure optimal performance, minimize parasitics, and reduce electromagnetic interference (EMI).
  • Qorvo recommends using their proprietary matching network design tool, QorvoMatch, to optimize the matching network for the RFAM3620SR. This tool helps to simplify the design process and ensures optimal performance. Additionally, Qorvo provides a matching network design guide (AN-12034) that provides more detailed information.
  • Although the datasheet specifies an operating temperature range of -40°C to 85°C, Qorvo recommends derating the device for extended reliability and performance. The recommended operating temperature range is -20°C to 70°C for most applications.
  • Proper thermal management is crucial for the RFAM3620SR. Qorvo recommends using a thermal pad or heat sink to dissipate heat. The device's thermal resistance (θJA) is specified in the datasheet. Ensure that the PCB design and layout allow for adequate heat dissipation to prevent overheating and reduce the risk of thermal shutdown.
  • Qorvo provides a separate document (AN-12035) that outlines the recommended soldering and assembly guidelines for the RFAM3620SR. It's essential to follow these guidelines to ensure reliable assembly and prevent damage to the device.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

RFAM3620SR Overview

Use the download button to access the RFAM3620SR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like RFAM3, or try a keyword search, such as RF/Microwave Amplifiers

About Qorvo

Qorvo is a prominent American semiconductor company that specializes in the design and manufacturing of radio frequency (RF) solutions. The company was formed in 2015 through the merger of TriQuint Semiconductor and RF Micro Devices. Qorvo's product portfolio encompasses a wide range of RF components and semiconductor technologies used in various applications, including wireless communications, aerospace and defense, and IoT (Internet of Things) devices.
