RH4V2-UDC24V - Idec

RH4V2-UDC24V Details

• Manufacturer Part Number:

  RH4V2-UDC24V

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  IDEC Corporation

• YTEOL:

  6.87

• Body Breadth:

  27.5 mm

• Body Height:

  35.6 mm

• Body Length or Diameter:

  41 mm

• Coil Operate Voltage(DC):

  19.2 V

• Coil Power:

  1500 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  388 Ω

• Coil Voltage(DC)-Max:

  26.4 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  10A@240VAC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  10 A

• Contact (DC) Max Rating R Load:

  10A@30VDC

• Contact Resistance:

  50 mΩ

• Contact Voltage(AC)-Max:

  240 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  200000 Cycle(s)

• End Contact Material:

  Silver Cadmium Oxide

• Input Switching Control Type:

  Random

• Insulation Resistance:

  100000000 Ω

• Number of Terminals:

  14

• Operate Time:

  25 ms

• Operating Temperature-Max:

  40 °C

• Operating Temperature-Min:

  -25 °C

• Physical Dimension:

  41mm x 27.5mm x 35.6mm

• Reference Standard:

  CSA; TUV; UL

• Relay Action:

  LATCHED

• Relay Form:

  4 FORM C

• Relay Function:

  4PDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  25 ms

• Terminal Length:

  0.004000508001016002 inch

• Termination Type:

  SOLDER
