RH7G04BBJFRATCB - ROHM Semiconductor

RH7G04BBJFRATCB Details

• Manufacturer Part Number:

  RH7G04BBJFRATCB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN3333T-8L, 8 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  5

• Avalanche Energy Rating (Eas):

  54 mJ

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  40 V

• Drain Current-Max (ID):

  40 A

• Drain-source On Resistance-Max:

  0.0119 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  230 pF

• JESD-30 Code:

  S-PDSO-N8

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, EMBOSSED, 13 INCH

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  P-CHANNEL

• Power Dissipation-Max (Abs):

  75 W

• Pulsed Drain Current-Max (IDM):

  80 A

• Reference Standard:

  AEC-Q101

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
