RJHSE-5384-02 - Amphenol

RJHSE-5384-02 Details

• Manufacturer Part Number:

  RJHSE-5384-02

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Unknown

• Country Of Origin:

  India

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  8

• Additional Feature:

  SHILEDED

• Board Mounting Option:

  SPLIT BOARD LOCK

• Body Breadth:

  0.53 inch

• Body Depth:

  0.62 inch

• Body Length:

  1.27 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  RJ CONNECTOR

• Contact Finish Mating:

  GOLD (50) OVER NICKEL (50)

• Contact Finish Termination:

  MATTE TIN OVER NICKEL

• Contact Gender:

  FEMALE

• Contact Material:

  PHOSPHOR BRONZE

• Contact Resistance:

  20 mΩ

• Contact Style:

  TELCOM, MODULAR

• Dielectric Withstanding Voltage:

  1000VAC V

• Durability:

  750 Cycles

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insertion Force-Max:

  22.24 N

• Insulation Resistance:

  500000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYETHYLENE

• JESD-609 Code:

  e3

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Option 2:

  MOUNTING FLANGE

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD AND PANEL

• Number of Ports:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• PCB Contact Pattern:

  STAGGERED

• Plating Thickness:

  50u inch

• Rated Current (Signal):

  1.5 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  COPPER ALLOY

• Terminal Length:

  0.1 inch

• Terminal Pitch:

  2.032 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  8

• UL Flammability Code:

  94V-0
