RLM-33+ - Mini-Circuits

Description: RF Wireless Misc LIMITER / SURF MOUNT / RoHS

Download RLM-33+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
RLM-33+ - Mini-Circuits PCB footprint - Other - Other - TT1224_2022
click to zoom
3D Models
RLM-33+ - Mini-Circuits  - 3D model - Other - TT1224_2022
click to zoom

RLM-33+ Details

  • Manufacturer Part Number:

    RLM-33+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    0.300 X 0.250 INCH, ROHS COMPLIANT, MINIATURE, CASE TT1224, 6 PIN

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • Adjustability:

    FIXED

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    30 dBm

  • Input Power-Min (CW):

    12 dBm

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    3000 MHz

  • Operating Frequency-Min:

    30 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Power-Max:

    11.5 dBm

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    DILCC6,.25

  • RF/Microwave Device Type:

    LIMITER

  • Surface Mount:

    YES

  • Terminal Finish:

    Gold (Au) - with Nickel (Ni) barrier

  • VSWR-Max:

    1.5

RLM-33+ Frequently Asked Questions (FAQs)

  • The RLM-33+ can handle up to 1W of input power, but it's recommended to derate the power to 0.5W for continuous operation to ensure reliability and prevent overheating.
  • The RLM-33+ has a 50 ohm input and output impedance. To impedance match, use a pi-network or a T-network topology with capacitors and inductors to match the impedance of your system to 50 ohms.
  • The RLM-33+ operates from -40°C to +85°C, but the optimal operating temperature range is between 0°C to 50°C for best performance and reliability.
  • Yes, the RLM-33+ is designed for high-reliability applications and is available in a compact, surface-mount package. However, it's essential to follow proper PCB design and assembly guidelines to ensure reliable operation.
  • To troubleshoot issues, check the input and output signals with a spectrum analyzer or oscilloscope, verify the power supply voltage, and ensure proper impedance matching. Consult the datasheet and application notes for more information.
