RM05-8A-S - Meder

RM05-8A-S Details

• Manufacturer Part Number:

  RM05-8A-S

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS AND REACH COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Standex-Meder Electronics

• YTEOL:

  0

• Body Breadth:

  7 mm

• Body Height:

  14.15 mm

• Body Length or Diameter:

  33 mm

• Coil Current(DC)-Max:

  0.01 A

• Coil Operate Voltage(DC):

  3.5 V

• Coil Power:

  10 mW

• Coil Release Voltage(DC):

  0.75 V

• Coil Resistance:

  500 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  .5A@170VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  .5A@170VDC

• Contact Voltage(AC)-Max:

  170 V

• Contact Voltage(DC)-Max:

  170 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Operate Time:

  0.6 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Physical Dimension:

  33mm x 7mm x 14.15mm

• Relay Action:

  MOMENTARY

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.1 ms

• Sealing:

  WATER PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER
