RN112BPC - Switchcraft

RN112BPC Details

• Manufacturer Part Number:

  RN112BPC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Switchcraft Conxall

• YTEOL:

  7

• Additional Feature:

  LOW PROFILE, 94V-0

• Audio Type:

  PHONO

• Body Breadth:

  0.676 inch

• Body Depth:

  1.28 inch

• Body Length:

  0.625 inch

• Body/Shell Style:

  JACK

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  6.3MM AUDIO

• Contact Gender:

  FEMALE

• Contact Resistance:

  20 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  500V V

• Durability:

  10000 Cycles

• IEC Conformance:

  NO

• Insertion Force-Max:

  35.59 N

• Insulation Resistance:

  10000000000 Ω

• Insulator Material:

  POLYETHYLENE

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Poles:

  3

• Number of Ports:

  1

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -20 °C

• Option:

  GENERAL PURPOSE

• Reference Standard:

  UL

• Terminal Length:

  0.157 inch

• Termination Type:

  SOLDER
