ROS-244R+ - Mini-Circuits

ROS-244R+ Details

• Manufacturer Part Number:

  ROS-244R+

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  7

• Additional Feature:

  TR, 7/13 INCH

• Control Voltage-Max:

  16 V

• Control Voltage-Min:

  2 V

• Modulation Sensitivity:

  10 MHz/V

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  16

• Offset Frequency:

  1 kHz

• Operating Frequency-Max:

  244 MHz

• Operating Frequency-Min:

  170 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Oscillator Type:

  VOLTAGE CONTROLLED OSCILLATOR

• Output Power:

  10 dBm

• Package Equivalence Code:

  LCC16,.5SQ,100

• Phase Noise:

  -94 dBc/Hz

• Physical Dimension:

  12.7mm x 12.7mm x 4.57mm

• Supply Current-Max:

  34 mA

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  YES
