RP115L331D-E2 - Ricoh

RP115L331D-E2 Details

• Manufacturer Part Number:

  RP115L331D-E2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  DFN-8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Ricoh Electronic Devices Co Ltd

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.17 V

• Dropout Voltage1-Nom:

  0.125 V

• Input Voltage Absolute-Max:

  6 V

• Input Voltage-Max:

  5.25 V

• Input Voltage-Min:

  3.8 V

• JESD-30 Code:

  R-PDSO-N8

• JESD-609 Code:

  e4

• Length:

  1.6 mm

• Line Regulation-Max:

  0.004785%

• Load Regulation-Max:

  0.04%

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -40 °C

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current1-Max:

  1 A

• Output Voltage1-Max:

  3.3495 V

• Output Voltage1-Min:

  3.2505 V

• Output Voltage1-Nom:

  3.3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC8,.05,16

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR

• Peak Reflow Temperature (Cel):

  260

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  0.4 mm

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  PALLADIUM

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Voltage Tolerance-Max:

  1.5%

• Width:

  1.2 mm
