RP117K151D-TR - Nisshinbo

RP117K151D-TR Details

• Manufacturer Part Number:

  RP117K151D-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN-6

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Nisshinbo Micro Devices

• YTEOL:

  6.1

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.7 V

• Dropout Voltage1-Nom:

  0.66 V

• Input Voltage Absolute-Max:

  0.3 V

• Input Voltage-Max:

  2.5 V

• Input Voltage-Min:

  10 V

• JESD-30 Code:

  S-PDSO-N6

• Length:

  1.2 mm

• Line Regulation-Max:

  0.0405%

• Load Regulation-Max(%):

  0.03%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature TJ-Max:

  125 °C

• Operating Temperature TJ-Min:

  -40 °C

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current1-Max:

  0.1 A

• Output Voltage1-Max:

  1.425 V

• Output Voltage1-Min:

  1.575 V

• Output Voltage1-Nom:

  1.5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VSON

• Package Equivalence Code:

  SOLCC6,.05,16

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, VERY THIN PROFILE

• Packing Method:

  TR

• Regulator Type:

  FIXED NEGATIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  0.4 mm

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  DUAL

• Voltage Tolerance-Max:

  5%

• Width:

  1.2 mm
