RP310048 - TE Connectivity

RP310048 Details

• Manufacturer Part Number:

  RP310048

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  12.6 mm

• Body Height:

  25.5 mm

• Body Length or Diameter:

  29 mm

• Coil Current(DC)-Max:

  0.01 A

• Coil Operate Voltage(DC):

  33.6 V

• Coil Power:

  500 mW

• Coil Release Voltage(DC):

  4.8 V

• Coil Resistance:

  4400 Ω

• Coil Voltage(DC)-Max:

  48 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  16A@440VAC

• Contact Current(AC)-Max:

  16 A

• Contact Current(DC)-Max:

  16 A

• Contact Voltage(AC)-Max:

  440 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  12 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  29mm x 12.6mm x 25.5mm

• Reference Standard:

  UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  6 ms

• Sealing:

  RT2

• Surface Mount:

  NO

• Termination Type:

  SOLDER
