RP3SL005 - TE Connectivity

RP3SL005 Details

• Manufacturer Part Number:

  RP3SL005

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.75

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.79

• Body Breadth:

  12.6 mm

• Body Height:

  25.5 mm

• Body Length or Diameter:

  29 mm

• Coil Current(AC)-Max:

  0.09 A

• Coil Current(DC)-Max:

  0.09 A

• Coil Power:

  500 mW

• Coil Resistance:

  54 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  16 A

• Contact Current(DC)-Max:

  16 A

• Contact Voltage(AC)-Max:

  400 V

• Contact Voltage(DC)-Max:

  300 V

• Dielectric Strength Between Coil and Contacts:

  4000 Vrms

• Dielectric Strength Between Open Contacts:

  2000 Vrms

• End Contact Material:

  SILVER TIN OXIDE INDIUM OXIDE

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  29 X 12.6 X 25.5

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  18 g
