RECOM Power Inc recommends a PCB layout with a large copper area connected to the module's thermal pad to dissipate heat efficiently. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
To ensure reliability in high-temperature environments, it is essential to follow the recommended derating curves for the module's output power and input voltage. Additionally, ensure good airflow around the module, and consider using a heat sink or a metal plate to dissipate heat. It is also recommended to follow the recommended storage and operating temperature ranges specified in the datasheet.
RECOM Power Inc recommends using a low-ESR ceramic capacitor with a value of 10uF to 22uF, rated for the input voltage range of the module. The capacitor should be placed as close as possible to the module's input pins to minimize noise and ripple.
Yes, the RP60-2415SG can be used in a redundant or parallel configuration to achieve higher power output or to improve system reliability. However, it is essential to follow the recommended guidelines for paralleling or redundancy, and to ensure that the modules are properly synchronized and monitored to prevent any potential issues.
The typical MTBF for the RP60-2415SG is around 1.5 million hours, calculated according to the Telcordia SR-332 standard. This value is based on the module's internal components and manufacturing process, and it may vary depending on the operating conditions and environment.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
RP60-2415SG Overview
Use the download button to access the RP60-2415SG schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like RP60-,
or try a keyword search, such as Power Supply Modules
