RPH-3.0-T - RECOM Power

RPH-3.0-T Details

• Manufacturer Part Number:

  RPH-3.0-T

• Part Life Cycle Code:

  Active

• Package Description:

  QCCN, LCC47,.39X.47,35

• Reach Compliance Code:

  Unknown

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  8

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  CURRENT/VOLTAGE-MODE

• Control Technique:

  PULSE WIDTH MODULATION

• Input Voltage-Max:

  55 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-PQCC-N47

• Length:

  12 mm

• Number of Functions:

  1

• Number of Terminals:

  47

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  3 A

• Output Voltage-Max:

  15 V

• Output Voltage-Min:

  1 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCN

• Package Equivalence Code:

  LCC47,.39X.47,35

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Seated Height-Max:

  4.1 mm

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK

• Switching Frequency-Max:

  640 kHz

• Technology:

  HYBRID

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.9 mm

• Terminal Position:

  QUAD

• Width:

  10 mm
