RPM5.0-3.0-CT - RECOM Power

RPM5.0-3.0-CT Details

• Manufacturer Part Number:

  RPM5.0-3.0-CT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LGA-25

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  6

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  97%

• Input Voltage-Max:

  17 V

• Input Voltage-Min:

  5.15 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  S-MXMA-N25

• JESD-609 Code:

  e4

• Length:

  12.19 mm

• Line Regulation-Max:

  3%

• Load Regulation-Max:

  3%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  3 A

• Output Voltage-Max:

  6 V

• Output Voltage-Min:

  0.9 V

• Output Voltage-Nom:

  3 V

• Package Body Material:

  METAL

• Package Code:

  XMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  THERMAL; OUTPUT OVER VOLTAGE; SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.02121 Vrms

• Seated Height-Max:

  4 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Gold/Nickel (Au/Ni)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  2.29 mm

• Terminal Position:

  UNSPECIFIED

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  15 W

• Trim/Adjustable Output:

  YES

• Width:

  12.19 mm
