RSW-2-25P+ - Mini-Circuits

RSW-2-25P+ Details

• Manufacturer Part Number:

  RSW-2-25P+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  ROHS COMPLIANT, CASE CL620, 14 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Mini-Circuits

• YTEOL:

  0.4

• 1dB Compression Point:

  28 dBm

• Additional Feature:

  HIGH ISOLATION

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  30 dBm

• Insertion Loss-Max:

  1.8 dB

• Isolation-Min:

  30 dB

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  14

• On Time-Nom:

  0.01 µs

• Operating Frequency-Max:

  2500 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP14,.25

• Port Termination:

  REFLECTIVE

• Power Supplies:

  5/7 V

• RF/Microwave Device Type:

  SPDT

• Surface Mount:

  YES

• Terminal Finish:

  MATTE TIN

• VSWR-Max:

  1.7
