RT4813AGQUF - RICHTEK

Description: Boost Switching Regulator IC Positive Adjustable 1.8V 1 Output 2.5A (Switch) 9-UFQFN

Download RT4813AGQUF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
RT4813AGQUF - RICHTEK PCB footprint - Other - Other - UQFN-9L 2x2 (FC) (U-Type)
click to zoom
3D Models
RT4813AGQUF - RICHTEK  - 3D model - Other - UQFN-9L 2x2 (FC) (U-Type)
click to zoom

RT4813AGQUF Details

  • Manufacturer Part Number:

    RT4813AGQUF

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    UQFN2x2-9(FC)

  • Manufacturer Package Code:

    UQFN2x2-9(FC)

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Richtek Technology Corp

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

RT4813AGQUF Frequently Asked Questions (FAQs)

  • A good PCB layout is crucial for the RT4813AGQUF. Richtek recommends a 4-layer PCB with a solid ground plane, and the IC should be placed near the input capacitors. The input and output traces should be kept short and wide to minimize ESR and ESL. A dedicated ground plane under the IC is also recommended.
  • To ensure stability, follow the recommended component values and PCB layout. Make sure the input and output capacitors are of high quality and have low ESR. Also, ensure the feedback network is properly designed and the loop gain is sufficient. If oscillations occur, try adding a small capacitor (e.g., 10nF) between the VOUT and GND pins.
  • Although the datasheet specifies a maximum input voltage of 18V, it's recommended to limit the input voltage to 15V to ensure reliable operation and prevent damage to the IC. Exceeding 15V may cause internal voltage regulators to malfunction or fail.
  • The RT4813AGQUF is rated for operation up to 125°C, but its performance may degrade at high temperatures. Ensure proper thermal design and heat dissipation to prevent overheating. If operating in high-temperature environments, consider using a heat sink or thermal interface material to keep the IC within its recommended operating temperature range.
  • When troubleshooting, start by verifying the input voltage, output voltage, and current. Check for proper PCB layout, component values, and soldering quality. Use an oscilloscope to monitor the output voltage and current waveforms. If issues persist, consult the datasheet and application notes, or contact Richtek's technical support for assistance.
