A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the input and output capacitors close to the IC, and use short and wide traces for the power lines.
Monitor the input voltage, output current, and junction temperature to ensure they are within the specified limits. Use thermal design and layout techniques to keep the junction temperature below 125°C.
A low-ESR ceramic capacitor with a value of 10uF to 22uF is recommended. The capacitor should be placed close to the VIN pin and have a low impedance path to the ground plane.
Choose an output capacitor with a low ESR and a value of 10uF to 47uF. The capacitor should be placed close to the VOUT pin and have a low impedance path to the ground plane.
Use a thermal pad on the PCB to connect the IC's thermal pad to a solid ground plane. Ensure good airflow around the IC and use a heat sink if necessary.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
RT8105GS Overview
Use the download button to access the RT8105GS schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like RT810,
or try a keyword search, such as Switching Regulator or Controllers
