Richtek provides a recommended PCB layout in their application note ANI03, which includes guidelines for thermal vias, copper pours, and component placement to ensure optimal thermal performance.
To optimize output voltage accuracy, ensure that the input voltage is within the recommended range, use a high-precision voltage reference, and minimize noise on the FB pin by using a low-pass filter and proper PCB layout.
The RT8290AGSP can drive a maximum capacitive load of 10uF, but it's recommended to use a smaller capacitor (e.g., 4.7uF) to ensure stability and prevent oscillations.
To prevent overheating, ensure good airflow around the device, use a heat sink if necessary, and monitor the junction temperature (TJ) to prevent it from exceeding the maximum rating of 150°C. Also, implement thermal shutdown protection by connecting the TSD pin to a voltage source.
Richtek recommends using a low-ESR ceramic capacitor (e.g., X5R or X7R) with a value of 10uF to 22uF for the input capacitor (CIN) to ensure stable operation and minimize input voltage ripple.
